Item Number: 47907867
Description: 1150M Tier 2 Crawler dozer
Language: English
Type: Service Manual
P.I.N.: PIN NCDC11500 and above, PIN NDDC11000 and above, PIN NEDC11000 and above, PIN NFDC11000 and above
Model: 1150M
SERVICE MANUAL
1150M Tier 2 Crawler Dozer
PIN NCDC11500 and above; PIN NDDC11000 and above;
PIN NEDC11000 and above; PIN NFDC11000 and above
Part number 47907867 2nd edition English October 2015 Replaces part number 47619915
1150M Power Angle Tilt (PAT) Blade, Long Track (LT) - Non-regulated [NCDC11500 - ] ,
1150M Power Angle Tilt (PAT) Blade, Long Track (LT) - Non-regulated [NDDC11000 - ] ,
1150M Power Angle Tilt (PAT) Blade, Long Track (LT) - Non-regulated [NEDC11000 - ] ,
1150M Power Angle Tilt (PAT) Blade, Long Track (LT) - Non-regulated [NFDC11000 - ] ,
1150M Power Angle Tilt (PAT) Blade, Wide Track (WT) - Non-regulated [NCDC11500 - ] ,
1150M Power Angle Tilt (PAT) Blade, Wide Track (WT) - Non-regulated [NDDC11000 - ] ,
1150M Power Angle Tilt (PAT) Blade, Wide Track (WT) - Non-regulated [NEDC11000 - ] ,
1150M Power Angle Tilt (PAT) Blade, Wide Track (WT) - Non-regulated [NFDC11000 - ]
Foreword - Important notice regarding equipment servicing
All repair and maintenance work listed in this manual must be carried out only by qualified dealership personnel,
strictly complying with the instructions given, and using, whenever possible, the special tools.
Anyone who performs repair and maintenance operations without complying with the procedures provided herein
shall be responsible for any subsequent damages.
The manufacturer and all the organizations of its distribution chain, including - without limitation - national, regional, or
local dealers, reject any responsibility for damages caused by parts and/or components not approved by the manufacturer,
including those used for the servicing or repair of the product manufactured or marketed by the manufacturer.
In any case, no warranty is given or attributed on the product manufactured or marketed by the manufacturer in case
of damages caused by parts and/or components not approved by the manufacturer.
The manufacturer reserves the right to make improvements in design and changes in specifications at any time without
notice and without incurring any obligation to install them on units previously sold. Specifications, descriptions, and
illustrative material herein are as accurate as known at time of publication but are subject to change without notice.
