Item Number: 87618255
Description: Deutz Engine for 21E,221E,321E Wheel Loaders
Language: Multiple Language
Type: Service Manual
Model: 21E, 221E, 321E, BF3 4L 2011, BF3 4M 2011, Deutz F2 4L 2011, F2 4M 2011
F O R E W O R D
Reliable engine operation is dependent on properly executed repairs as well as adjustment work.
This Workshop Manual describes the appropriate operations for any repair and adjustment work
on the engine and engine components. It is presumed that this work will be carried out by qualified
personnel.
This operation manual has been designed for quick and easy understanding. Therefore the concise
text passages are accompanied by pictographs to illustrate the relevant operation.
Aspects of operation and maintenance are dealt with in the respective Operation Manual.
For spare parts orders the respective spare parts catalogue should be referred to.
This Workshop Manual is not subject to engineering change service and is valid until next issue.
Therefore please refer to the information in our Technical Circulars when carrying out repairs.
General information:
- Please read carefully and observe the instructions given in this Workshop Manual
to avoid accidents and ensure that your engine always functions properly and
reliably.
- Make sure that this Workshop Manual is readily available for all those carrying out
repairs or adjustments and that the contents are well understood.
- Non-compliance with these repair instructions may result in malfunction and engine
damage as well as personal injuries for which the manufacturer shall not accept any
liability.
- The accident prevention regulations and all other generally recognized regulations
on safety and occupational medicine are to be observed.
- A prerequisite for successful repair is that all required equipment, hand and special tools
are available and in perfect working order.
- Optimal operation economy, reliability and durability of the engine can only be ensured
when genuine parts of DEUTZ AG are used.
- Engine components such as springs, clamps, snap rings, etc. may cause injury if not
handled with care.
- Engine repairs must be carried out in accordance with intended use as defined by
the equipment manufacturer. For conversions, only parts approved by DEUTZ AG for
a specific purpose should be used.
